Nieuport Nieuport 11

Fighter Biplane

Nieuport 11 French Air Force / Armée de l
Photo ©: Karsten Palt
The Nieuport 11 is a single-engine single-seat fighter biplane aircraft produced by the French manufacturer Nieuport S.A.d E..
The Nieuport 11 was also licence-built in Italy by Aeronautica Macchi as the Nieuport 11000.
Crew1
Propulsion1 Rotary Engine
Engine ModelLe Rhône 9C
Engine Power60 kW80 hp
Speed156 km/h84 kts
  97 mph
Service Ceiling4.500 m14.764 ft
Range330 km178 NM
205 mi.
Empty Weight320 kg706 lbs
max. Takeoff Weight480 kg1.058 lbs
Wing Span7,52 m24 ft 8 in
Wing Area13,0 m²140 ft²
Length5,64 m18 ft 6 in
Height2,40 m7 ft 10 in
First Flight1915
Production Statusout of production
Total Productionca. 7200
Data for (Version)Nieuport 11

next aircraft
[Photo-ID: 231] © Karsten Palt 2006-11-17
Nieuport 11, , , c/n ,© Karsten Palt, 2006Nieuport
11

Replica
Luftfahrtmuseum Laatzen-Hannover [Laatzen]
[Photo-ID: 12314] © Karsten Palt 2016-04-10
Nieuport 11, , n/a, c/n ,© Karsten Palt, 2016Nieuport
11
Reg.: n/a

Replica
EAA AirVenture Museum [Oshkosh, WI]
[Photo-ID: 6167] © Karsten Palt 2012-06-14
Nieuport 11, , N1256, c/n n/a, Replica,© Karsten Palt, 2012Nieuport
11
Reg.: N1256
c/n: n/a, Replica

Replica
San Diego Air and Space Museum [San Diego, CA]
[Photo-ID: 6168] © Karsten Palt 2012-06-14
Nieuport 11, , N1256, c/n n/a, Replica,© Karsten Palt, 2012Nieuport
11
Reg.: N1256
c/n: n/a, Replica

Replica
San Diego Air and Space Museum [San Diego, CA]
[Photo-ID: 10829] © Karsten Palt 2015-04-04
Nieuport 11, French Air Force / Armee de l Air, , c/n ,© Karsten Palt, 2015Nieuport
11
French Air Force / Armee de l Air

last surviving Nieuport 11 Bebe
Musee de l Air et de l Espace [Paris Le Bourget]
