Saab Saab-105
Jet Trainer / Ground-Attack Aircraft
The Saab 105 is a twin-engined two-seat trainer and light ground-attack aircraft produced by the Swedish manufacturer Saab AB. The Saab 105 is also used as a reconaissance aircraft and as a four-seat liaison aircraft. Swedish Air Force (Flygvapnet) designation is SK 60.
The Saab 105 is only operated by the Swedish Air Force and the Austrian Armed Forces (Saab 105Ö). The two-seat versions can also be used as a four-seat liaison aircraft by replacement of the two ejection seats. The Saab 105 (SK 60) was originally powered by two Turbomeca Aubisque low-bypass turbofan engines, license-built by Svenska Flygmotor as RM9. Most Swedisch SK 60 were later (starting in 1995) modified by replacement of the engines with Williams FJ 44-1C (Volvo Aero RM15) turbofan engines.
Crew | 2 |
Propulsion | 2 Turbojet Engines | |
Engine Model | General Electric J85-17B | |
Engine Power (each) | 12,7 kN | 2850 lbf |
Speed | 970 km/h | 524 kts 603 mph |
Service Ceiling | 13.100 m | 42.979 ft |
Range | 2.000 km | 1.080 NM 1.243 mi. |
Empty Weight | 2.565 kg | 5.655 lbs |
max. Takeoff Weight | 6.500 kg | 14.330 lbs |
Wing Span | 9,50 m | 31 ft 2 in |
Wing Area | 16,3 m² | 175 ft² |
Length | 10,80 m | 35 ft 5 in |
Height | 2,70 m | 8 ft 10 in |
First Flight | 29.06.1963 | |
Production Status | out of production | |
Total Production | 190 |
ICAO Code | SB05 | |
Data for (Version) | Saab 105Oe | |
Variants | SK 60A, SK 60B, SK 60C, SK 60E, Saab 105Ö |
[Photo-ID: 11987] © Karsten Palt 2001-07-27 | |
Saab 105 SK-60 Swedish Air Force / Flygvapnet Reg.: 60141 c/n: 60141 | |
Royal International Air Tattoo 2001 [Royal Air Force Station Cottesmore (EGXJ)] |
[Photo-ID: 2315] © Karsten Palt 2009-06-19 | |
Saab 105Oe Austrian Armed Forces / Bundesheer Reg.: BG-37 c/n: 105437 Blue G | |
Luchtmachtdagen 2009 [Volkel (EHVK / UDE)] |
